fischer Stand-off installation TherMax 10/200 M8 - 20 pieces
Product no.: F514253
fischer Stand-off installation TherMax 10/200 M8
Applications
For the thermally separated fixing of:
- Signs, Lighting, Letter boxes, Motion detectors, Downpipes, Lightning rods, Blind guide rails
Building materials
- Concrete, Vertically perforated brick, Hollow blocks made from lightweight concrete, Perforated sand-lime brick, Solid sand-lime brick, Building brick, Aerated concrete, Wood
Technical data
Min. screw length ls 22mm + thickness of mounting member tfix; for use in wood without universal plug UX, consider drill hole diameter in footnote under load table.
| Drill hole diameter | d0 | 12 | [mm] |
| Drill hole depth | h0 | 260 | [mm] |
| Max. thickness of non-bearing layer | e | 180 - 200 | [mm] |
| Anchorage depth | hef | 70 | [mm] |
| Cover cap-Ø | ADK | 22 | [mm] |
| Width across nut | SW | 13 | [mm] |
| Chipboard / metric / sheet metal screw | M8 | ||
Price:
125,90 EUR
19 % VAT incl. excl. Shipping costs
6,30 EUR per piece
