Applications
Building materials
Technical data
| Drill hole diameter | d0 | 12 | [mm] |
| Min. drill hole depth | h1 | 85 | [mm] |
| Min. panel thickness | dp | - | [mm] |
| Min. bolt penetration | IE, min | 68 | [mm] |
| Anchor length | l | 60 | [mm] |
| Wood and chipboard screws | ds / ds x ls | 8 x 80 | [mm] |
| Drive | SW13 | ||
| Max. fixture thickness | tfix | 12 | [mm] |
